Photometrics

• Light Source:
  — 1 x 120W RGBL
  — 48 x 1W RGBWW
• Beam Angle: 3.8° - 38°
• Output: 93,750 Lux @ 2m (3.8° Zoom)
• Flicker-free operation
• 140mm Fresnel Lens
• LED Lifespan: 50,000 hours

Effects

• Dimming: 0-100%, 16 bit
• Aura LEDs Effects (RGB LEDs)
• Strobe: Yes
• Zoom: Motorised, 3.8° - 38°

Movement

• Pan: 540°

• Tilt: 230°

Power

• Input Voltage: 100-240V AC, 50/60 Hz
• Power consumption Max.: 180W
• Connection: IP65 True1 in/out

Control

• Operation Modes: DMX, auto, sound active, master/slave
• Control Protocol: DMX, ArtNet, sACN
• DMX Channels: 20 / 38 / 222
• Control Interface: 5-pin DMX in/out, RJ45 in / out
• Display: LCD control panel


Housing

• Housing Materials: ABS and steel, matte black finish
• IP Rate: IP65
• Size: 282 x 250 x 365 mm
• Net Weight: 7 kg

Download DMX Chart

Download the User Manual

Warranty: 3 years
